Product Change NoticesGeneral Specifications
Part No.
M2012TJW03
Description
Snap-in Mount Miniature Rockers
Name
Rocker
Series
M
Status
Active
Poles
SPDT
Circuits
On-On
Current Rating
6A (AC), 4A (DC)
Rating (AC)
125V
Rating (DC)
30V
Actuator Type
Actuator Arm, Cap Required
Actuator Marking
Varies by Cap
Mounting Type
Panel Mount, Snap-In
Termination Style
PC Pin
Features
Epoxy Sealed Terminals
panel cutout dimensions
Rectangular - 15.90mm x 12.50mm
Rating
6
Illumination
Non-Illuminated
