UB06KW016B

INDICATOR RECT BLCK HSNG WHT LED

UB Series
INDICATOR RECT BLCK HSNG WHT LED

3D CAD Model Download Specifications Custom Assembly Check Inventory Sample Request Form Environmental Compliance Product Change Notices

Support Documentation

Standards & Approvals Product Training Modules Processing Data - PDF Electrical Ratings - PDF Lamps and LEDs - PDF
General Specifications
Part No.
UB06KW016B
Description
INDICATOR RECT BLCK HSNG WHT LED
Series
UB
Type
LED
Lamp Color
White
Voltage Rating
3.8V
Current
25mA
Lens Style Size
Rectangle with Flat Top, 17.00mm x 12.00
panel cutout dimensions
0.88" x 0.64" (22.35mm x 16.26mm)
ratings
Vf (Typ), If (Max)
panel cutout shape
Rectangular
Rating
0.025
